Tpye of Battery

Shockli 18650 3100mah IMR 40A

Size(mm)

18.3±0.2mm(Diameter) x 65mm±0.2mm(Length)

Weight(g)

48±1g

Nominal Voltage

3.7V

Nominal  Capacity

3100mah (1A  Discharge)

Discharge Cut-off voltage

2.5 V

Standard Charge

0.3 A~3A (Recommend 0.5 A~1.2A) /4.2V±0.05V

Maximum charge current

3A

Continuous

Discharge Current

35A

MAX

Discharge Current

40A

Initial Impedance

＜20 mW

Cycle Life

500times: discharging capacity≥60%

Charging Time

Standard charge : 3hours

Rapid charge : 1hours

Operating environment

Charging, 0°C ~ 45°C

Discharging, -20°C~60°C

Storage environment

Temp(-20°c ~25°c) / Humidity (65±20%)

Minimum Order Quantity

50 Piece

Application

Electronic cigarette ,Flashlight
